Appendix C Pin Assignments Appendices
TECRA A9(S5/P5/S200) Maintenance Manual (960-633)[CONFIDENTIAL] C-27
C.35 CN9601 Serial interface connector (9-pin)
Table C-35 Serial interface connector (9-pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 DCD-PYN I 2 RXD-PYN I
3 TXD-PYN O 4 DTR-PYP O
5 GND - 6 DSR-PYP I
7 RTS-PYP O 8 CTS-PYP I
9 RING-PYP I
1T GND - 2T GND -
Fingerprint Sensor board (FHMLF*)
C.36 CN9650 System board(FHMLS*) interface connector (8-pin)
Table C-35 System board interface connector (8-pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 GND
-
2 NC
-
3 E3V
-
4 FGSPON-S3N
O
5 GND
-
6 ZUSBFS-E3N
I/O
7 ZUSBFS-E3P
I/O
8 GND
-
1T GND
- -
