Toshiba TECRA A9 Series Maintenace Manual

4.6 HDD 4 Replacement Procedures
4.6 HDD
CAUTION: When handling the HDD, do not press the top and bottom surface as shown by
the arrow. Hold it by the sides.
Removing the HDD
To remove the HDD, follow the steps below and refer to Figure 4-5 to 4-7.
1. Turn the computer upside down.
2. Remove the following screws securing the HDD cover.
3. Insert your finger into the slot and lift the HDD cover to remove.
• M2.5×6B FLAT HEAD screw ×2
HDD cover
M2.5×6B FLAT HEAD
Slot
Figure 4-5 Removing the HDD cover
TECRA A9/TECRA S5/TECRA P5/Satellite Pro S200 Maintenance Manual (960-633) [CONFIDENTIAL] 4-13

Toshiba TECRA A9 Series Specifications

General

Processor	Intel Core 2 Duo
Display	15.4-inch
Display Resolution	1280 x 800 pixels
RAM	Up to 4 GB
Operating System	Windows Vista
Optical Drive	DVD-RW
Wireless	802.11a/g/n
Ports	USB 2.0, VGA, Ethernet, Headphone
