Appendix C Pin Assignments Appendices
TECRA A9(S5/P5/S200) Maintenance Manual (960-633)[CONFIDENTIAL] C-21
C.21 CN6050 Internal microphone connector (2-pin)
Table C-21 Internal microphone connector (2-pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 (IMICIN-PXP) I 2 A-GND -
C.22 J6051 External microphone connector (6-pin)
Table C-22External Microphone connector (6-pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 A-GND - 2 (EMICIN-PXP) -
3 (EMICB-P2V) - 4 A-GND -
5 DETCTA-P4N I 6 EMICB-P2V I
C.23 CN6170 Speaker connector (4-pin)
Table C-23 Speaker (Right) connector (4-pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 SPOTL-PXN O 2 SPOTL-PXP O
3 SPOTR-PXP O 4 SPOTR-PXN O
