Toshiba TECRA A9 Series Maintenace Manual

Appendix C Pin Assignments Appendices
TECRA A9(S5/P5/S200) Maintenance Manual (960-633)[CONFIDENTIAL] C-25
C.33 CN2170 Smart Card interface connector (10-pin)
Table C-32 Smart Card interface connector (10-pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1
SCC4-PYP
O 2
SCCLK-PYP
-
3
SCRST-PYN
O 4
VCC
5
SCDET-P3N
I 6
GND
7
GND
8
NC
9
SCIO-PYP
I/O 10
EGATE-P3N
I/O
1T
GND
2T
GND

Toshiba TECRA A9 Series Specifications

General

Processor	Intel Core 2 Duo
Display	15.4-inch
Display Resolution	1280 x 800 pixels
RAM	Up to 4 GB
Operating System	Windows Vista
Optical Drive	DVD-RW
Wireless	802.11a/g/n
Ports	USB 2.0, VGA, Ethernet, Headphone
