4 Replacement Procedures 4.5 SmartCard (SmartCard model only)
4.5 SmartCard (SmartCard model only)
Removing the SmartCard
To remove the SmartCard, follow the steps below and refer to Figure 4-4.
CAUTION: Before you remove the SmartCard, refer to the Card’s documentation and to
your operating system documentation for proper procedures and
precautions.
1. Hold both sides of the SmartCard and remove it out horizontally.
SmartCard
Figure 4-4 Removing the SmartCard
Installing the SmartCard
To install the SmartCard, follow the steps below and refer to Figure 4-4.
1. Insert the SmartCard into the card slot horizontally.
4-12 [CONFIDENTIAL] TECRA A9/TECRA S5/TECRA P5/Satellite Pro S200 Maintenance Manual (960-633)
