Appendix C Pin Assignments Appendices
TECRA A9(S5/P5/S200) Maintenance Manual (960-633)[CONFIDENTIAL] C-15
C.9 CN2650 Mini PCI Express I/F connector(Robson) (52-pin)
Table C-9 Mini PCI Express interface connector (52-pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 2 P3V
3 4 GND
5 6 1R5-P1V
7 ROBXRQ-P3N I 8
9 GND 10
11 XPEROB-P0N I 12
13 XPEROB-P0P I 14
15 GND 16
17 18 GND
19 20
21 GND 22 PLTRS2-E3N O
23 ZERROB-P1N O 24
25 ZERROB-P1P O 26 ROBMDL-P3N O
27 GND 28 1R5-P1V
29 GND 30
31 SIG42832 I 32
33 SIG42833 I 34 GND
35 GND 36
37 GND 38
39 40 GND
41 42
43 44
45 46
47 48 1R5-P1V
49 50 GND
51 52 P3V
1T GND 2T GND
