Appendices Appendix C Pin Assignments
C-14 [CONFIDENTIAL]TECRA A9(S5/P5/S200) Maintenance Manual (960-633)
C.8 CN2600 Mini PCI Express I/F connector (W-LAN)(52-pin)
Table C-8 Mini PCI Express interface connector (52-pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 PEWAKE-E3N O 2 P3V I
3 WCHDAT-P3P O 4 GND -
5 WCHCLK-P3P O 6 1R5-P1V I
7 MPEXRQ-P3N I 8 NC -
9 GND - 10 NC -
11 XPEMPE-P0N O 12 NC -
13 XPEMPE-P0P O 14 NC -
15 GND - 16 NC -
17 NC - 18 GND -
19 NC - 20 WLRFON-S3N O
21 GND - 22 PLTRS3-E3N -
23 ZERWL-P1N I 24 E3V I
25 ZERWL-P1P I 26 GND -
27 GND - 28 1R5-P1V I
29 GND - 30 NC -
31 ZETWL-P1N O 32 NC -
33 ZETWL-P1P O 34 GND -
35 GND - 36 ZUSBWL-E3N I/O
37 GND - 38 ZUSBWL-E3P I/O
39 NC - 40 GND -
41 NC - 42 NC -
43 GND - 44 NC -
45 XCLCK1-E1P I/O 46 NC -
47 CLDAT1-E1P I/O 48 1R5-P1V I
49 CLRST1-E3N I/O 50 GND -
51 NC - 52 P3V I
1T GND - 2T GND -
