Appendices Appendix C Pin Assignments
C-4 [CONFIDENTIAL]TECRA A9(S5/P5/S200) Maintenance Manual (960-633)
C.2 CN1410 SO-DIMM1 connector (200-pin)
Table C-2 SO-DIMM1 connector (200-pin) (1/3)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 MRVREF-B0V I 2 GND -
3 GND - 4 BDQ01-B1P I/O
5 BDQ04-B1P I/O 6 BDQ00-B1P I/O
7 BDQ05-B1P I/O 8 GND -
9 GND - 10 BDM0-B1P I
11 BDQS0-B1N I/O 12 GND -
13 BDQS0-B1P I/O 14 BDQ07-B1P I/O
15 GND - 16 BDQ06-B1P I/O
17 BDQ03-B1P I/O 18 GND -
19 BDQ02-B1P I/O 20 BDQ11-B1P I/O
21 GND - 22 BDQ08-B1P I/O
23 BDQ13-B1P I/O 24 GND -
25 BDQ12-B1P I/O 26 BDM1-B1P I
27 GND - 28 GND -
29 BDQS1-B1N I/O 30 XMCK3-B1P I
31 BDQS1-B1P I/O 32 XMCK3-B1N I
33 GND - 34 GND -
35 BDQ10-B1P I/O 36 BDQ15-B1P I/O
37 BDQ09-B1P I/O 38 BDQ14-B1P I/O
39 GND - 40 GND -
41 GND - 42 GND -
43 BDQ21-B1P I/O 44 BDQ16-B1P I/O
45 BDQ22-B1P I/O 46 BDQ20-B1P I/O
47 GND - 48 GND -
49 BDQS2-B1N I/O 50 TSDIMB-P3N
(NC)
-
51 BDQS2-B1P I/O 52 BDM2-B1P I
53 GND - 54 GND -
55 BDQ19-B1P I/O 56 BDQ23-B1P I/O
57 BDQ17-B1P I/O 58 BDQ18-B1P I/O
59 GND - 60 GND -
61 BDQ24-B1P I/O 62 BDQ25-B1P I/O
