Appendix C Pin Assignments Appendices
TECRA A9(S5/P5/S200) Maintenance Manual (960-633)[CONFIDENTIAL] C-5
Table C-2 SO-DIMM1 connector (200-pin) (2/3)
Pin No. Signal Name I/O Pin No. Signal Name I/O
63 BDQ29-B1P I/O 64 BDQ28-B1P I/O
65 GND - 66 GND -
67 BDM3-B1P I 68 BDQS3-B1N I/O
69 N.C. - 70 BDQS3-B1P I/O
71 GND - 72 GND -
73 BDQ31-B1P I/O 74 BDQ27-B1P I/O
75 BDQ30-B1P I/O 76 BDQ26-B1P I/O
77 GND - 78 GND -
79 MCKE3-B1P I 80 MCKE4-B1P I
81 1R8-B1V I 82 1R8-B1V I
83 N.C. - 84 N.C -
85 BBS2-B1P I 86 BMA14-B1P -
87 1R8-B1V I 88 1R8-B1V I
89 BMA12-B1P I 90 BMA11-B1P I
91 BMA09-B1P I 92 BMA07-B1P I
93 BMA08-B1P I 94 BMA06-B1P I
95 1R8-B1V I 96 1R8-B1V I
97 BMA05-B1P I 98 BMA04-B1P I
99 BMA03-B1P I 100 BMA02-B1P I
101 BMA01-B1P I 102 BMA00-B1P I
103 1R8-B1V I 104 1R8-B1V I
105 BMA10-B1P I 106 BBS1-B1P I
107 BBS0-B1P I 108 BRAS-B1N I
109 BWE-B1N I 110 MCS2-B1N I
111 1R8-B1V I 112 1R8-B1V I
113 BCAS-B1N I 114 MODT2-B1P I
115 MCS3-B1N I 116 BMA13-B1P I
117 1R8-B1V I 118 1R8-B1V I
119 MODT3-B1P I 120 N.C -
121 GND - 122 GND -
123 BDQ38-B1P I/O 124 BDQ39-B1P I/O
125 BDQ36-B1P I/O 126 BDQ37-B1P I/O
127 GND - 128 GND -
129 BDQS4-B1N I/O 130 BDM4-B1P I
131 BDQS4-B1P I/O 132 GND -
133 GND - 134 BDQ34-B1P I/O
