Toshiba TECRA A9 Series Maintenace Manual

Appendices Appendix C Pin Assignments
C-6 [CONFIDENTIAL]TECRA A9(S5/P5/S200) Maintenance Manual (960-633)
Table C-2 SO-DIMM1 connector (200-pin) (3/3)
Pin No. Signal Name I/O Pin No. Signal Name I/O
135 BDQ35-B1P I/O 136 BDQ32-B1P I/O
137 BDQ33-B1P I/O 138 GND -
139 GND - 140 BDQ43-B1P I/O
141 BDQ40-B1P I/O 142 BDQ46-B1P I/O
143 BDQ45-B1P I/O 144 GND -
145 GND - 146 BDQS5-B1N I/O
147 BDM5-B1P I 148 BDQS5-B1P I/O
149 GND - 150 GND -
151 BDQ47-B1P I/O 152 BDQ42-B1P I/O
153 BDQ41-B1P I/O 154 BDQ44-B1P I/O
155 GND - 156 GND -
157 BDQ52-B1P I/O 158 BDQ55-B1P I/O
159 BDQ49-B1P I/O 160 BDQ50-B1P I/O
161 GND - 162 GND -
163 N.C. - 164 XMCK4-B1P I
165 GND - 166 XMCK4-B1N I
167 BDQS6-B1N I/O 168 GND -
169 BDQS6-B1P I/O 170 BDM6-B1P I
171 GND - 172 GND -
173 BDQ53-B1P I/O 174 BDQ54-B1P I/O
175 BDQ48-B1P I/O 176 BDQ51-B1P I/O
177 GND - 178 GND -
179 BDQ56-B1P I/O 180 BDQ62-B1P I/O
181 BDQ57-B1P I/O 182 BDQ63-B1P I/O
183 GND - 184 GND -
185 BDM7-B1P I 186 BDQS7-B1N I/O
187 GND - 188 BDQS7-B1P I/O
189 BDQ60-B1P I/O 190 GND -
191 BDQ61-B1P I/O 192 BDQ59-B1P I/O
193 GND - 194 BDQ58-B1P I/O
195 SMBDT1-E3P I/O 196 GND -
197 SMBCK1-E3P I/O 198 GND -
199 M-E3V I 200 M-E3V I
1T GND - 2T GND -

Toshiba TECRA A9 Series Specifications

General

Processor	Intel Core 2 Duo
Display	15.4-inch
Display Resolution	1280 x 800 pixels
RAM	Up to 4 GB
Operating System	Windows Vista
Optical Drive	DVD-RW
Wireless	802.11a/g/n
Ports	USB 2.0, VGA, Ethernet, Headphone
