Toshiba TECRA A9 Series - CN5080 RGB Interface Connector (15-Pin; CN9600 System Board(Fhmls*)Interface Connector (40-Pin; Serial & RGB Board (FHMLR*)

Appendices Appendix C Pin Assignments
C-26 [CONFIDENTIAL]TECRA A9(S5/P5/S200) Maintenance Manual (960-633)
Serial & RGB board (FHMLR*)
C.34 CN5080 RGB interface connector (15-pin)
Table C-34 RGB interface connector (15-pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 MRED-PXP O 2 MGRN-PXP O
3 MBLU-PXP O 4 NC -
5 GND - 6 GND -
7 GND - 8 GND -
9 P5V - 10 GND -
11 NC - 12 CRTSDA-P5P I/O
13 MHSYNC-P5P O 14 MVSYNC-P5P O
15 CRTSCL-P5P I/O
1T GND -
2T
GND -
C.35 CN9600 System board(FHMLS*)interface connector (40-pin)
Table C-35 System board I/F connector (40-pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1
GND
2
GND
3 4
5
P5V
6
P5V
7
P5V
8
P5V
9 10
11
GND
12
GND
13
CRT1SD-P5P
O 14
CRT1SC-P5P
O
15
M1VSYN-P3P
O 16
M1HSYN-P3P
O
17
GND
18
TXD-PYN
19
DTR-PYP
I 20
DSR-PYP
O
21
RTS-PYP
I 22
RXD-PYN
O
23
GND
24
GND
25
CTS-PYP
O 26
GND
27
DCD-PYP
O 28
GND
29
RING-PYP
O 30
GND
31
GND
32
GND
33 MBLUE-PXP O 34
VGAGND
35
M1GRN-PXP
O 36
VGAGND
37
M1RED-PXP
O 38
VGAGND
39
GND
40
GND
