Appendices Appendix B Board Layout
B-2 [CONFIDENTIAL]TECRA A9(S5/P5/S200) Maintenance Manual (960-633)
Table B-1 System board (FHMLS*) connectors (front) Rev D
Number Name
CN2110 PC card interface connector
CN2600 Mini PCI Express interface connector (Wireless LAN)
CN3230 Keyboard interface connector
CN3240 Dual Point interface connector
CN3490 (Debug Port interface connector)
W3401 (Debugging short-circuit of a serial model)
CN4400 Bluetooth interface connector
CN4440 (Bluetooth2 interface connector)
CN5000 LCD interface connector
CN6050 Internal microphone connector
CN6170 Speaker interface connector
CN9300 RTC Battery interface connector
CN9540 (Web Camera interface connector)
CN9550 Fingerprint sensor(FHMLF*) board I/F connector
CN9721 Switch interface connector
CN2170 Smart Card I/F connector
