Appendices Appendix B Board Layout
B-4 [CONFIDENTIAL]TECRA A9(S5/P5/S200) Maintenance Manual (960-633)
Table B-2 System board( FHMLS*) ICs and connectors (back)
Number Name
IS1050 CPU socket
IC1200 Intel 965GM/GML (Northbridge)
IC1600 ICH8-M(Southbridge)
IC5000 nVIDIA G8M
CN1400 SO-DIMM0 connector A
CN1410 SO-DIMM0 connector B
CN1810 ODD interface connector
CN1900 HDD(SATA) interface connector
IS2140 Bridge Media interface connector
CN2300 Docking interface connector
CN2650
(Mini PCI Express I/F connector (Robson: not
used))
CN3010 MDC interface connector
CN4100 LAN interface connector
CN4230 IEEE 1394 interface connector
CN4610 USB port 4 connector
CN4612 USB port 6 connector
J6051 External microphone connector
J6310 Headphone connector
CN8771 FAN interface connector
CN8800 DC-IN connector
CN8810 Main Battery connector
CN9500 Serial & RGB(FHMLR*) board I/F connector
