E6582175
F-14
6
<Frequency setting mode selection>
[Parameter setting]
Title Function Adjustment range Default setting
Frequency setting mode selection 1
0: Setting dial 1(save even if power is off)
1: Terminal VIA
2: Terminal VIB
3: Setting dial 2(press in center to save)
4: RS485 communication
5: UP/DOWN from external logic input
6: CANopen communication
7: Communication option
8: Terminal VIC
9, 10: -
11: Pulse train input
12, 13: -
14: sro
0
Note) When setting the frequency by an extension panel option, fmod/f207 is set to 0 or 3.
[Programmed value]
:
Setting dial 1
Frequencies are set by rotating the setting dial on the inverter. Like the position
of notches in a volume knob, the frequency setting value at the position of the
notch is saved.
The frequency setting value is set by keys on an extension panel option.
Refer to section 3.2.2
:
Terminal VIA
A frequency command is set by means of external analog signals.
(VIA terminal: 0 –10Vdc)
Refer to section 3.2.2 and 7.3
:
Terminal VIB
A frequency command is set by means of external analog signals.
(VIB terminal: 0 - +10Vdc or -10 - +10Vdc)
Refer to section 3.2.2 and 7.3
:
Setting dial 2
Frequencies are set by rotating the setting dial on the inverter. Press the center
of the setting dial to save the frequency setting value.
The frequency setting value is set by keys on an extension panel option.
Refer to section 3.2.2
:
RS485
communication
Frequencies are set by RS485 communication from an external device.
Refer to section 6.38
:
UP/DOWN from
external logic input
Frequencies are set by up/down commands from a terminal.
Refer to section 6.10.4
:
CANopen
communication
Frequencies are set by CANopen communication from an external device.
Refer to “CANopen communication Instruction Manual E6581911”.
To Next Page
