Toshiba Tosvert VF-S15 User Manual

E6582175
F-15
6
:
Communication
option
Frequencies are set by commands from a communication option.
 Refer to each Instruction Manual of option.
:
Terminal VIC
A frequency command is set by means of external analog signals.
(VIC terminal: 0 (4) - 20mAdc)
 Refer to section 3.2.2 and 7.3
:
Pulse train input
A frequency command is set by means of external pulse train signals.
(S2 terminal: 10pps - 2kpps)
 Refer to section 6.10.5
14: sro
Frequencies are set by sro parameter.
 Refer to section 5.7.
● The control input terminal in which the following functions are set is always valid regardless of the setting of
 and .
 Reset (valid only for tripping)
 Standby
 External input tripping stop command
 Coast stop command terminal
● To make changes in the command mode selection  and the frequency setting mode selection 1
, first stop the inverter temporarily.
(Can be changed while in operation when  is set to .)
● Priority commands from communications or terminal blocks are given priority over .
 Preset-speed operation
: Set to  (Terminal block operation)
: Valid in all setting values.
 Input terminal settings
Assign the following functions to the input terminal to allow switching of the frequency command by turning
the terminal ON/OFF.
Input terminal function ON OFF
48 Forced local from communication
Enabled during communication
Local (Setting of , )
Communication
106
Frequency setting mode terminal
block
Terminal block (VIA) enabled setting of 
Each of the following numbers (49, 107) are reverse signals.

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
