E6582175
F-38
6
[Parameter setting]
Title Function Adjustment range Default setting
f107
Analog input terminal
selection (VIB)
0: 0-+10V
1: -10-+10V
0
f109
Analog/logic input
selection (VIA/VIB)
0: VIA - analog input
VIB - analog input
0
1: VIA - analog input
VIB - contact input
2: -
3: VIA - contact input (Sink)
VIB - contact input
4: VIA - contact input (Source)
VIB - contact input
f201
VIA input point 1 setting
0-100 (%) 0
f202
VIA input point 1 frequency
0.0-500.0 (Hz) 0.0
f203
VIA input point 2 setting
0-100 (%) 100
f204
VIA input point 2 frequency
0.0-500.0 (Hz) *1
f209
Analog input filter
2-1000 (ms) 64
f210
VIB input point 1 setting
-100-+100 (%) 0
f211
VIB input point 1 frequency
0.0-500.0 (Hz) 0.0
f212
VIB input point 2 setting
-100-+100 (%) 100
f213
VIB input point 2 frequency
0.0-500.0 (Hz) *1
f216
VIC input point 1 setting
0-100 (%) 0
f217
VIC input point 1 frequency
0.0-500.0 (Hz) 0
f218
VIC input point 2 setting
0-100 (%) 100
f219
VIC input point 2 frequency
0.0-500.0 (Hz) *1
f810
Communication command
point selection
0: Disabled
1: Enabled
0
f811
Communication command
point 1 setting
0-100 (%) 0
f812
Communication command
point 1 frequency
0.0-fh (Hz) 0
f813
Communication command
point 2 setting
0-100 (%) 100
f814
Communication command
point 2 frequency
0.0-fh (Hz) *1
*1: Default setting values vary depending on the setup menu. Refer to section 11.5.
Note 1: Do not set point 1 and 2 to the same value. If they are set to the same value, err1 is displayed.
