Toshiba Tosvert VF-S15 User Manual

E6582175
F-60
6
(Input voltage above 480V)
VFS15-
Ambient
temperature
PWM carrier frequency
2.0k~4.0kHz 4.1k~12.0kHz 12.1k~16.0kHz
4004PL-W1
40C or less
1.5 A 1.5 A 1.2 A
Above 40  50C
1.5 A 1.5 A 1.2 A
Above 50  60C
1.4 A 1.2 A 1.0 A
4007PL-W1
40C or less
2.1 A 1.9 A 1.9 A
Above 40  50C
2.1 A 1.9 A 1.9 A
Above 50  60C
2.0 A 1.5 A 1.5 A
4015PL-W1
40C or less
3.8 A 3.4 A 3.1 A
Above 40  50C
3.8 A 3.4 A 3.1 A
Above 50  60C
3.6 A 2.7 A 2.5 A
4022PL-W1
40C or less
5.1 A 4.6 A 4.2 A
Above 40  50C
5.1 A 4.6 A 4.2 A
Above 50  60C
4.8 A 3.7 A 3.4 A
4037PL-W1
40C or less
8.7 A 7.9 A 6.9 A
Above 40  50C
8.7 A 7.9 A 6.9 A
Above 50  60C
8.3 A 6.3 A 5.5 A
4055PL-W1
40C or less
13.2 A 12.0 A 12.0 A
Above 40  50C
13.2 A 12.0 A 12.0 A
Above 50  60C
12.5 A 9.6 A 9.6 A
4075PL-W1
40C or less
15.6 A 14.2 A 12.4 A
Above 40  50C
15.6 A 14.2 A 12.4 A
Above 50  60C
14.8 A 11.4 A 9.9 A
4110PL-W1
40C or less
25.5 A 23.0 A 23.0 A
Above 40  50C
25.5 A 23.0 A 23.0 A
Above 50  60C
24.2 A 18.4 A 18.4 A
4150PL-W1
40C or less
30.4 A 27.6 A 24.0 A
Above 40  50C
30.4 A 27.6 A 24.0 A
Above 50  60C
28.9 A 22.1 A 19.2 A
Note 1) : Inverter rated output current
(Carrier frequency 4kHz or less, ambient temperature 40C or less )
Note 2) When ambient temperature is above 40C, remove the protective label on the top of the inverter.
The condition of the load reduction (current reduction) on the table:
“Normal installation”. (Refer to 1.4.4)
For 40C or less: with the top protective label
For above 40C : without the top protective label

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
