Toshiba Tosvert VF-S15 User Manual

E6582175
F-59
6
[500V class]
In case of aul=1 (constant torque characteristic (150%-60s) setting)
(Input voltage 480V or less)
VFS15- Ambient temperature
PWM carrier frequency
2.0k~4.0kHz 4.1k~12.0kHz 12.1k~16.0kHz
4004PL-W1
40C or less
1.5 A 1.5 A 1.5 A
Above 40  50C
1.5 A 1.5 A 1.5 A
Above 50  60C
1.4 A 1.2 A 1.2 A
4007PL-W1
40C or less
2.3 A 2.1 A 2.1 A
Above 40  50C
2.3 A 2.1 A 2.1 A
Above 50  60C
2.2 A 1.7 A 1.7 A
4015PL-W1
40C or less
4.1 A 3.7 A 3.3 A
Above 40  50C
4.1 A 3.7 A 3.3 A
Above 50  60C
3.9 A 3.0 A 2.6 A
4022PL-W1
40C or less
5.5 A 5.0 A 4.5 A
Above 40  50C
5.5 A 5.0 A 4.5 A
Above 50  60C
5.2 A 4.0 A 3.6 A
4037PL-W1
40C or less
9.5 A 8.6 A 7.5 A
Above 40  50C
9.5 A 8.6 A 7.5 A
Above 50  60C
9.0 A 6.9 A 6.0 A
4055PL-W1
40C or less
14.3 A 13.0 A 13.0 A
Above 40  50C
14.3 A 13.0 A 13.0 A
Above 50  60C
13.6 A 10.4 A 10.4 A
4075PL-W1
40C or less
17.0 A 17.0 A 14.8 A
Above 40  50C
17.0 A 17.0 A 14.8 A
Above 50  60C
16.2 A 13.6 A 11.8 A
4110PL-W1
40C or less
27.7 A 25.0 A 25.0 A
Above 40  50C
27.7 A 25.0 A 25.0 A
Above 50  60C
26.3 A 20.0 A 20.0 A
4150PL-W1
40C or less
33.0 A 30.0 A 26.0 A
Above 40  50C
33.0 A 30.0 A 26.0 A
Above 50  60C
31.4 A 24.0 A 20.8 A

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
