Toshiba Tosvert VF-S15 User Manual

E6582175
F-58
6
 Load reduction (current reduction) by carrier frequency, ambient temperature and
input volgate
[240V class]
In case of aul=1 (Constant torque characteristic (150%-60s)) setting.
VFS15-
VFS15S-
Ambient temperature
PWM carrier frequency
2.0k~4.0kHz 4.1k~12.0kHz 12.1k~16.0kHz
2002PL-W1
40C or less
1.5 A 1.5 A 1.5 A
Above 40  50C
1.5 A 1.2 A 1.2 A
Above 50  60C
1.2 A 1.1 A 1.1 A
2004PM/L-W1
40C or less
3.3 A 3.3 A 3.3 A
Above 40  50C
3.3 A 2.6 A 2.6 A
Above 50  60C
2.6 A 2.5 A 2.5 A
2007PM/L-W1
40C or less
4.8 A 4.4 A 4.2 A
Above 40  50C
4.8 A 3.5 A 3.4 A
Above 50  60C
3.8 A 3.3 A 3.2 A
2015PM/L-W1
40C or less
8.0 A 7.9 A 7.1 A
Above 40  50C
8.0 A 7.9 A 7.1 A
Above 50  60C
7.6 A 6.3 A 5.7 A
2022PM/L-W1
40C or less
11.0 A 10.0 A 9.1 A
Above 40  50C
11.0 A 10.0 A 9.1 A
Above 50  60C
10.5 A 8.0 A 7.3 A
2037PM-W1
40C or less
17.5 A 16.4 A 14.6 A
Above 40  50C
17.5 A 16.4 A 14.6 A
Above 50  60C
16.6 A 13.1 A 11.7 A
2055PM-W1
40C or less
27.5 A 25.0 A 25.0 A
Above 40  50C
27.5 A 25.0 A 25.0 A
Above 50  60C
26.1 A 20.0 A 20.0 A
2075PM-W1
40C or less
33.0 A 33.0 A 29.8 A
Above 40  50C
33.0 A 33.0 A 29.8 A
Above 50  60C
31.4 A 26.4 A 23.8 A
2110PM-W1
40C or less
54.0 A 49.0 A 49.0 A
Above 40  50C
54.0 A 49.0 A 49.0 A
Above 50  60C
51.3 A 39.2 A 39.2 A
2150PM-W1
40C or less
66.0 A 60.0 A 54.0 A
Above 40  50C
66.0 A 60.0 A 54.0 A
Above 50  60C
62.7 A 48.0 A 43.2 A

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
