E6582175
F-131
6
When f707 is not 0.00, and f708 is not 0
The value displayed on the panel can be changed in steps.
(In the case of the setting “initial panel display selection”
f710 = 0 [Output frequency])
Panel display = Output frequency ×
[Parameter setting]
Title Function Adjustment range Default setting
f707
Free step 1 (1-step rotation of setting
dial)
0.00: Automatic
0.01-
fh (Hz)
0.00
f708
Free step 2 (panel display)
0: Automatic
1-255
0
Operation example 1
f707 = 0.00 (Automatic)
By rotating the setting dial 1 step, the panel frequency command value changes only 0.1 Hz.
When
f707 = 10.00 (Hz) is set
Rotating the setting dial 1 step changes the panel frequency command value in 10.00 Hz increments, from
0.00 up to 60.00 (Hz).
Operation example 2
When f707=1.00 (Hz), and f708=1:
By rotating the setting dial 1 step, the frequency setting
fc changes in steps of 1Hz: 0 1 2 ... 60
(Hz) and also the value displayed on the operation panel changes in steps of 1. Use these settings to hide
decimal fractions and also the value displayed on the operation panel changes in steps of 1. Use these
settings to hide decimal fractions.
6.34.5 Select the initial display of the panel
f710 : Initial panel display selection
f720 : Initial extension panel display selection
Function
This parameter specifies display format of the standard monitor mode when power is ON. Different
contents can be displayed on the operation panel of main unit and the extension panel (option).
Changing the display format while power is ON
When the power is ON, the standard monitor mode displays the output frequency (default setting) such as
"
0.0" or "off". This format can be changed to any other monitor display format by setting f710.
However, the initial letter including
t or c will not be displayed. When the power is ON, set the display of the
extension panel at
f720.
● Different contents can be displayed on the operation panel of main unit and the extension panel (option).
To Next Page
