Toshiba Tosvert VF-S15 User Manual

E6582175
F-132
6
[Parameter setting]
Title Function Adjustment range Default setting
f710
Initial panel display selection
0: Output frequency (Hz/free unit)
1: Output current (%/A)
2: Frequency command value (Hz/free unit)
3: Input voltage (DC detection) (%/V)
4: Output voltage (command value) (%/V)
5: Input power (kW)
6: Output power (kW)
7: Torque (%)
8: -
9: Motor cumulative load factor (%)
10: Inverter cumulative load factor (%)
11: PBR (Braking resistor) cumulative load
factor (%)
12: Stator frequency (Hz/free unit)
13: VIA input value (%)
14: VIB input value (%)
15 to 17: -
18: Arbitrary code from communication
19: -
20: VIC input value (%)
21: Pulse train input value (pps)
22: -
23: PID feedback value (Hz/free unit)
24: Integral Input power (kWh)
25: Integral Output power (kWh)
26: Motor load factor (%)
27: Inverter load factor (%)
28: Inverter rated current (A)
29: FM output value (%)
30: Pulse train output value (pps)
31: Cumulative power on time (100 hours)
32: Cumulative fan operation time (100
hours)
33: Cumulative operation time (100 hours)
34: Number of starting (10000 times)
35: Forward number of starting (10000
times)
36: Reverse number of starting (10000
times)
37: Number of trip (times)
38, 39: -
40: Inverter rated current (Carrier
frequency corrected)
41 to 51: -
52: Frequency command value /
output frequency (Hz/free unit)
53: PBR (Braking resistor) load factor (%)
0
f720
Initial extension panel display
selection
0
● For details on f710 / f720=18, see “Communication Function Instruction Manual : E6581913”.
Note: If
f720=18 setting, fixed value is displayed.

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
