E6582175
G-11
7
Note 1) ON with positive logic : Open collector output transistor or relay turned ON.
OFF with positive logic : Open collector output transistor or relay turned OFF.
ON with negative logic : Open collector output transistor or relay turned OFF.
OFF with negative logic : Open collector output transistor or relay turned ON.
● Refer to section 11.7 for details about the output terminal functions or levels.
