Toshiba Tosvert VF-S15 User Manual

E6582175
I-4
9
(2) Use shielded power cables, such as inverter output cables, and shielded control cables. Route the cables and
wires so as to minimize their lengths. Keep a distance between the power cable and the control cable and
between the input and output wires of the power cable. Do not route them in parallel or bind them together.
Instead, if necessary, cross at right angle.
(3) It is more effective in limiting the radiated noise to install the inverter in a sealed steel cabinet. Using wires as
thick and short as possible, earth the metal plate and the control panel securely with a distance kept between
the earth cable and the power cable.
(4) Route the input and output wires apart as far as possible from each other.
(5) To suppress radiated noise from cables, ground all shielded cables through a noise cut plate.
It is effective to earth shielded cables in the vicinity of the inverter and cabinet (within a radius of 10cm from
each of them). Inserting a ferrite core in a shielded cable is even more effective in limiting the radiated noise.
(6) To further limit the radiated noise, insert a zero-phase reactor in the inverter output line and insert ferrite cores
in the earth cables of the metal plate and cabinet.

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
