E6582175
I-5
9
Motor wiring (Shielded cables)
U/T1, V/T2, W/T3
Power supply wiring (Shielded cables)
R/L1, S/L2, S/L2/N, T/L3
Fixed by
insulation lock
EMC plate
Install the shield cable after
modifying it as shown below.
Control wiring (Shielded cables)
Control wiring (Shielded cables)
Remove the covering
of the cable and fix the shield
in the metal saddle.
Braking resistor wiring (Shielded cables)
PA/+, PB
[Example of wiring]
