Toshiba Tosvert VF-S15 User Manual

E6582175
K-2
11
 Basic parameters
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference

0003 Command mode
selection
- - 0: Terminal block
1: Panel keypad (including extension
panel)
2: RS485 communication
3: CANopen communication
4: Communication option
1 3.2
6.2.1
7.3

0004 Frequency setting
mode selection 1
*13
- - 0: Setting dial 1(save even if power is
off)
1: Terminal VIA
2: Terminal VIB
3: Setting dial 2(press in center to
save)
4: RS485 communication
5: UP/DOWN from external logic
input
6: CANopen communication
7: Communication option
8: Terminal VIC
9, 10: -
11: Pulse train input
12, 13: -
14: sro
0 3.2
6.2.1
6.10.1
5.8
7.3

0005 Meter selection - - 0: Output frequency
1: Output current
2: Frequency command value
3: Input voltage (DC detection)
4: Output voltage (command value)
5: Input power
6: Output power
7: Torque
8: -
9: Motor cumulative load factor
10: Inverter cumulative load factor
11: PBR (Braking resistor) cumulative
load factor
12: Stator frequency
13: VIA input value
14: VIB input value
15: Fixed output 1
(output current 100% equivalent)
16: Fixed output 2
(output current 50% equivalent)
17: Fixed output 3
(Other than the output current)
18: RS485 communication data
19: For adjustments ( set value is
displayed.)
20: VIC input value
21, 22: -
23: PID feedback value
24: Integral input power
25: Integral output power
26-52: -
53: PBR (Braking resistor) load factor
0 5.1

0006 Meter adjustment
gain
- - - -

0008 Forward/reverse
run selection
(Panel keypad)
- - 0: Forward run
1: Reverse run
2: Forward run (F/R switching on
extension panel)
3: Reverse run (F/R switching on
extension panel)
0 6.2.2
*13: When setting the frequency by an extension panel option, fmod/f207 is set to 0 or 3.

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
