Toshiba Tosvert VF-S15 User Manual

E6582175
K-3
11
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference

0009 Acceleration time
1
s 0.1/0.1 0.0-3600 (360.0) *8 10.0 5.2

0010 Deceleration time
1
s 0.1/0.1 0.0-3600 (360.0) *8 10.0

0011 Maximum
frequency
Hz 0.1/0.01 30.0-500.0 80.0 5.3

0012 Upper limit
frequency
Hz 0.1/0.01 0.5- *1 5.4

0013 Lower limit
frequency
Hz 0.1/0.01 0.0- 0.0

0014 Base frequency 1 Hz 0.1/0.01 20.0-500.0 *1 5.5

0409 Base frequency
voltage 1
V 1/0.1 50-330 (240V class)
50-660 (500V class)
*1 5.5
6.19.6

0015 V/F control mode
selection
- - 0: V/F constant
1: Variable torque
2: Automatic torque boost control
3: Vector control
4: Energy-saving
5: Dynamic energy-saving
(For fan and pump)
6: PM motor control
7: V/F 5-point setting
8: -
*1 6.3

0016 Torque boost
value 1
% 0.1/0.1 0.0-30.0 *2 6.4

0600 Motor electronic-
thermal protection
level 1
%
(A)
1/1 10-100 *12 100 5.6
6.29.1

0017 Electronic-thermal
protection
characteristic
selection
- -
Setting Overload protection
OL stall 0 5.6
0
Standard
motor
valid invalid
1 valid valid
2 invalid invalid
3 invalid valid
4
VF motor
valid invalid
5 valid valid
6 invalid invalid
7 invalid valid

0030 Preset-speed
frequency 0
Hz 0.1/0.01 - 0.0 5.7

0018 Preset-speed
frequency 1
Hz 0.1/0.01 - 0.0

0019 Preset-speed
frequency 2
Hz 0.1/0.01 - 0.0

0020 Preset-speed
frequency 3
Hz 0.1/0.01 - 0.0

0021 Preset-speed
frequency 4
Hz 0.1/0.01 - 0.0

0022 Preset-speed
frequency 5
Hz 0.1/0.01 - 0.0

0023 Preset-speed
frequency 6
Hz 0.1/0.01 - 0.0

0024 Preset-speed
frequency 7
Hz 0.1/0.01 - 0.0

0025 Set value of PID
control
Hz 0.1/0.01
f368 - 
0.0
6.24
*1: Default setting values vary depending on the setup menu setting. Refer to section 11.5.
*2: Default setting values vary depending on the capacity. Refer to section 11.4.
*8: These parameters can be changed to 0.01s unit by setting f519=1.
*12: When f701=1, adjustment range is 100%=rated current, or 100%=200V(240V class)/ 400V(500V class).

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
