Toshiba Tosvert VF-S15 User Manual

E6582175
K-9
11
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference

0249 PWM carrier
frequency during
DC braking
kHz 0.1/0.1 2.0-16.0 4.0 6.12.1

0250 DC braking
starting frequency
Hz 0.1/0.01 0.0- 0.0

0251 DC braking
current
%(A) 1/1 0-100 *12 50

0252 DC braking time s 0.1/0.1 0.0-25.5 1.0

0254 Motor shaft fixing
control
- - 0: Disabled
1: Enabled (after DC braking)
0 6.12.2

0256 Time limit for
lower-limit
frequency
operation
s 0.1/0.1 0: Disabled
0.1-600.0
0.0 6.13

0257 Factory specific
coefficient 2B
- - - -
* 3

0258 Factory specific
coefficient 2C
- - - -
* 3

0259 Lower limit
frequency reach
time limit at start-
up
s 0.1/0.1 0.0: Disabled
0.1-600.0
0.0 6.13

0260 Jog run frequency Hz 0.1/0.01
－20.0
5.0 6.14

0261 Jog run stopping
pattern
- - 0: Deceleration stop
1: Coast stop
2: DC braking stop
0

0262 Panel jog run
operation mode
- - 0: Invalid
1: Valid
0

0264 External logic
input - UP
response time
s 0.1/0.1 0.0-10.0 0.1 6.10.4

0265 External logic
input - UP
frequency steps
Hz 0.1/0.01 0.0- 0.1

0266 External logic
input - DOWN
response time
s 0.1/0.1 0.0-10.0 0.1

0267 External logic
input - DOWN
frequency steps
Hz 0.1/0.01 0.0- 0.1

0268 Initial value of
UP/DOWN
frequency
Hz 0.1/0.01

0.0

0269 Change of the
initial value of
UP/DOWN
frequency
- - 0: Not changed
1: Setting of  changed when
power is turned off
1

0270 Jump frequency 1 Hz 0.1/0.01 0.0- 0.0 6.15

0271 Jumping width 1 Hz 0.1/0.01 0.0-30.0 0.0

0272 Jump frequency 2 Hz 0.1/0.01 0.0- 0.0

0273 Jumping width 2 Hz 0.1/0.01 0.0-30.0 0.0

0274 Jump frequency 3 Hz 0.1/0.01 0.0- 0.0

0275 Jumping width 3 Hz 0.1/0.01 0.0-30.0 0.0
*3: Factory specific coefficient parameters are manufacturer setting parameters. Do not change the value of these parameters.
*12: When f701=1, adjustment range is 100%=rated current, or 100%=200V(240V class)/ 400V(500V class).

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
