Toshiba Tosvert VF-S15 User Manual

E6582175
K-10
11
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference

0287 Preset-speed
frequency 8
Hz 0.1/0.01 - 0.0 5.7

0288 Preset-speed
frequency 9
Hz 0.1/0.01 - 0.0

0289 Preset-speed
frequency 10
Hz 0.1/0.01 - 0.0

0290 Preset-speed
frequency 11
Hz 0.1/0.01 - 0.0

0291 Preset-speed
frequency 12
Hz 0.1/0.01 - 0.0

0292 Preset-speed
frequency 13
Hz 0.1/0.01 - 0.0

0293 Preset-speed
frequency 14
Hz 0.1/0.01 - 0.0

0294 Preset-speed
frequency 15
Hz 0.1/0.01 - 0.0 5.7
6.30

0295 Bumpless
operation selection
- - 0: Disabled
1: Enabled
0 6.16

0297 Low voltage
operation upper
limit frequency
Hz 0.1/0.01 0.0: Disabled
0.1-30.0
0.0 6.17

0298 Low voltage
operation DC
voltage
Vdc 1/0.1 240V class: 72(96)-168 *11
500V class: 72(96)-336 *11
120
*11: 240V class : 4.0kW or less : 72 to 168V, 5.5kW or more : 96 to 168V.
500V class : 4.0kW or less : 72 to 336V, 5.5kW or more : 96 to 336V.

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
