Toshiba Tosvert VF-S15

E6582175
K-14
11
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference

0349
Acceleration/decele
ration suspend
function
- 1/1
0:Disabled
1:Parameter setting
2:Terminal input
0

6.23

0350
Acceleration
suspend frequency
Hz 0.1/0.01 0.0- 0.0


0351
Acceleration
suspend time
s 0.1/0.1 0.0-10.0 0.0


0352
Deceleration
suspend frequency
Hz 0.1/0.01 0.0- 0.0


0353
Deceleration
suspend time
s 0.1/0.1 0.0-10.0
0.0


0359 PID control
waiting time
s 1/1 0-2400 0 6.24

0360 PID control - - 0: Disabled
1: Process type PID control
2: Speed type PID control
0

0361 Delay filter s 0.1/0.1 0.0-25.0 0.1

0362 Proportional gain - 0.01/0.01 0.01-100.0 0.30

0363 Integral gain s
-1
0.01/0.01 0.01-100.0 0.20

0366 Differential gain s 0.01/0.01 0.00-2.55 0.00

0367 Upper limit of set
value
Hz 0.1/0.01 0.0- *1

0368 Lower limit of set
value
Hz 0.1/0.01 0.0- 0.0

0369 PID control
feedback signal
selection
- - 0: Disabled
1: Terminal VIA
2: Terminal VIB
3: Terminal VIC
4 to 6: -
0

0372 Process increasing
rate (speed type
PID control)
s 0.1/0.1 0.1-600.0 10.0

0373 Process decreasing
rate (speed type
PID control)
s 0.1/0.1 0.1-600.0 10.0

0375 Factory specific
coefficient 3E
- - - -
* 3

0376 Factory specific
coefficient 3F
- - - -

0378 Number of pulse
train input
pps 1/1 10-500 25 6.10.5

0380 PID forward/reverse
characteristics
selection
- - 0: Forward
1: Reverse
0 6.24

0382
Hit and stop
control
- -
0: Disabled
1: Enabled
2: -
0
6.22.2

0383 Hit and stop
control frequency
Hz 0.1/0.01
0.1-30.0 5.0
*1: Default setting values vary depending on the setup menu setting. Refer to section 11.5.
*3: Factory specific coefficient parameters are manufacturer setting parameters. Do not change the value of these parameters.
