Toshiba Tosvert VF-S15 User Manual

E6582175
Q-2
17
Environments
Location of use
Indoors; not exposed to direct sunlight, corrosive gas, explosive gas, flammable gas,
oil mist, or dust; and vibration of less than 5.9m/s
2
(10 to 55Hz).
Elevation 1000 m or less
Ambient temperature
-10 to +40°C (50°C)
Maximum Surrounding Air Temperature
40 °C (with the protective label on the top of the inverter)
50 °C (without the protective label on the top of t he inverter,
except 0.75 kW or less in 200/240 V class)
Storage temperature -25 to +70°C (Temperature appli cable for a short term.)
Relative humidity 5 to 95% (free from condensation and vapor).
Current reduction
According to the carrier frequency f300 setting, you may need to reduce the inverter’s continuous output current.
Reduction rates vary depending on the capacity of the inverter.
[Single-phase/Three-phase 200/240V class]
VFS15-
VFS15S-
Ambient temperature
Input voltage 200V to 240V
PWM carrier frequency
2.0k to 4.0kHz 4.1k to 12.0kHz
2002PL-W1
40°C or less
1.5 A
2004PM-W1
2004PL-W1
40°C or less
3.3 A
2007PM-W1
2007PL-W1
40°C or less
4.8 A
2015PM-W1
2015PL-W1
40°C or less
8.0 A 7.9 A
Above 40 to 50°C
8.0 A
2022PM-W1
2022PL-W1
40°C or less
11.0 A 10.0 A
Above 40 to 50°C
11.0 A
[Three-phase 200/240V class]
VFS15- Ambient temperature
Input voltage 200V to 240V
PWM carrier frequency
2.0k to 4.0kHz 4.1k to 12.0kHz
2037PM-W1
40°C or less
17.5 A 16.4 A
Above 40 to 50°C
17.5 A
2055PM-W1
40°C or less
27.5 A 25.0 A
Above 40 to 50°C
27.5 A
2075PM-W1
40°C or less
33.0 A 33.0 A
Above 40 to 50°C
33.0 A
2110PM-W1
40°C or less
54.0 A 49.0 A
Above 40 to 50°C
54.0 A
2150PM-W1
40°C or less
66.0 A 60.0 A
Above 40 to 50°C
66.0 A
Note ) For 0.75 kW or less in 200/240 V class, maintain the ambient temperature of 40°C or less and th e PWM carrier
frequency of 4kHz or less for the compliance with UL standard. For "Above 40°C to 50°C" of the ambient
temperature except 0.75 kW or less in 200/240 V class, remove the protective label on the top of the inverter for
the compliance with UL standard.
