Toshiba Tosvert VF-S15 User Manual

E6582175
Q-3
17
[Three-phase 400/500V class]
VFS15-
Ambient
temperature
Input voltage 380V to 480V Input voltage Above 480V to 500V
PWM carrier frequency PWM carrier frequency
2.0k to 4.0kHz 4.1k to 12.0kHz 2.0k to 4.0kHz 4.1k to 12.0kHz
4004PL-W1
40°C or less
1.5 A 1.5 A
1.5 A 1.5 A
Above 40 to 50°C
1.5 A
1.5 A
4007PL-W1
40°C or less
2.3 A 2.1 A
2.1 A 1.9 A
Above 40 to 50°C
2.3 A
2.1 A
4015PL-W1
40°C or less
4.1 A 3.7 A
3.8 A 3.4 A
Above 40 to 50°C
4.1 A
3.8 A
4022PL-W1
40°C or less
5.5 A 5.0 A
5.1 A 4.6 A
Above 40 to 50°C
5.5 A
5.1 A
4037PL-W1
40°C or less
9.5 A 8.6 A
8.7 A 7.9 A
Above 40 to 50°C
9.5 A
8.7 A
4055PL-W1
40°C or less
14.3 A 13.0 A
13.2 A 12.0 A
Above 40 to 50°C
14.3 A
13.2 A
4075PL-W1
40°C or less
17.0 A 17.0 A
15.6 A 14.2 A
Above 40 to 50°C
17.0 A
15.6 A
4110PL-W1
40°C or less
27.7 A 25.0 A
25.5 A 23.0 A
Above 40 to 50°C
27.7 A
25.5 A
4150PL-W1
40°C or less
33.0 A 30.0 A
30.4 A 27.6 A
Above 40 to 50°C
33.0 A
30.4 A
3. Compliance with Connection
Use the UL conformed cables (Rating 75 °C or more, Use the copper conductors only.) to the main circuit terminals (R/L1,
S/L2, T/L3, U/T1, V/T2, W/T3).
⇒ For recommended tightening torque, see Table 1.
⇒ Use the ring terminal for the earth cables, see Table 2.
⇒ For recommended electric wire sizes, see Table 3,4.
⇒ Use the electric wire of Class1 for the control circuits.
For instruction in the United States, Integral solid state short circuit protection does not provide branch circuit protection.
Branch circuit protection must be provided in accordance with the National Electrical Code and any additional local codes.
For instruction in the Canada, Integral solid state short circuit protection does not provide branch circuit protection. Branch
circuit protection must be provided in accordance with the Canadian Electrical Code and any additional local codes.
Table 1 Tighten the screws to specified torque
Recommended tightening torque for screws on the terminal board
N·m Ib·in
M3.5 1.0 8.9
M4 1.4 12.4
M5 2.4 20.8
M6 4.5 40.0
M4 (grounding terminal) 1.4 12.4
M5 (grounding terminal) 2.8 24.8

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
