Toshiba Tosvert VF-S15 User Manual

E6582175
Q-4
17
Table 2 Ring terminal sizes for earth cables
Earth Cable Sizes M4 (grounding terminal) M5 (grounding terminal)
AWG14 R2-4 [JIS standard] R2-5 [JIS standard]
AWG12 R5.5-4 [JIS standard] R5.5-5 [JIS standard]
AWG10 R5.5-4 [JIS standard] R5.5-5 [JIS standard]
AIC, Fuse and Wire sizes
Use the UL listed fuses at connecting to power supply.
Short circuit test is performed under the condition of the power supply short-circuit currents in below.
These interrupting capacities and fuse rating currents depend on the applicable motor capacities.
Table 3 AIC, Fuses and Wire sizes
Inverter model
Voltage
(V)
Input
withstand
rating (kA)
Output
Interrupt
rating (kA)
Branch circuit
protection
Rating
(A)
Cable sizes of
power circuit
Earth Cable
Marking Y (1) X (2) Z1 Z2 - -
VFS15-2004PM-W1 240 5 5 Class CC 7 AWG 14 AWG 14
VFS15-2007PM-W1 240 5 5 Class J 15 AWG 14 AWG 14
VFS15-2015PM-W1 240 5 5 Class J 25 AWG 14 AWG 14
VFS15-2022PM-W1 240 5 5 Class J 25 AWG 12 AWG 14
VFS15-2037PM-W1 240 5 5 Class J 45 AWG 10 AWG 10
VFS15-2055PM-W1 240 22 5 Class J 60 AWG 8 AWG 10
VFS15-2075PM-W1 240 22 5 Class J 70 AWG 6 AWG 10
VFS15-2110PM-W1 240 22 5 Class J 100 AWG 6*2 AWG 8
VFS15-2150PM-W1 240 22 5 Class J 110 AWG 6*2 AWG 8
VFS15S-2002PL-W1 240 1 5 Class CC 7 AWG 14 AWG 14
VFS15S-2004PL-W1 240 1 5 Class J 15 AWG 14 AWG 14
VFS15S-2007PL-W1 240 1 5 Class J 25 AWG 14 AWG 14
VFS15S-2015PL-W1 240 1 5 Class J 40 AWG 10 AWG 12
VFS15S-2022PL-W1 240 1 5 Class J 45 AWG 10 AWG 10
VFS15-4004PL-W1 500 5 5 Class CC 6 AWG 14 AWG 14
VFS15-4007PL-W1 500 5 5 Class CC 6 AWG 14 AWG 14
VFS15-4015PL-W1 500 5 5 Class CC 12 AWG 14 AWG 14
VFS15-4022PL-W1 500 5 5 Class J 15 AWG 14 AWG 14
VFS15-4037PL-W1 500 5 5 Class J 25 AWG 12 AWG 14
VFS15-4055PL-W1 500 22 5 Class J 40 AWG 10 AWG 10
VFS15-4075PL-W1 500 22 5 Class J 40 AWG 8 AWG 10
VFS15-4110PL-W1 500 22 5 Class J 60 AWG 8 AWG 10
VFS15-4150PL-W1 500 22 5 Class J 70 AWG 6 AWG 10
Suitable for use on a circuit capable of delivering not more than___X___rms symmetrical kilo Amperes,___Y___Volts
maximum, when protected by___Z1___with a maximum rating of___Z2___.

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
