Toshiba Tosvert VF-S15 User Manual

E6582175
Q-5
17
(1) Input withstand rating is that for which the product has been designed thermally.
(2) Output interrupt rating relies on Integral solid state short circuit protection. This does not provide branch circuit
protection. Branch circuit protection must be provided in accordance with the National Electrical Code and any
additional local codes. This is dependant on the type of installation.
In case of using with a higher AIC capability up to 100kA(*1), the Short Circuit Current Ratings (SCCR) become 100kA(*1)
by installing with the circuit breakers(GV3P) or the fuses listed in Table 4.
Table 4 AIC 100kA, Fuses, Circuit breakers and Wire sizes
Inverter model
Voltage
(V)
Branch circuit protection
Cable sizes of
power circuit
Earth Cable
With Fuses With circuit breakers
Class (*2)
Rating
(A)
Type-Form
(*3)
Setting
(A)
VFS15-2004PM-W1 240 Class J 10 GV3P13 9 AWG 14 AWG 14
VFS15-2007PM-W1 240 Class J 15 GV3P13 9 AWG 14 AWG 14
VFS15-2015PM-W1 240 Class J 25 GV3P13 10 AWG 14 AWG 14
VFS15-2022PM-W1 240 Class J 25 GV3P18 18 AWG 12 AWG 14
VFS15-2037PM-W1 240 Class J 45 GV3P25 25 AWG 10 AWG 10
VFS15-2055PM-W1 240 Class J 60 GV3P40 40 AWG 8 AWG 10
VFS15-2075PM-W1 240 Class J 70 GV3P50 50 AWG 6 AWG 10
VFS15-2110PM-W1 240 Class J 100 GV3P65 65 AWG 6*2 AWG 8
VFS15-2150PM-W1 240 Class J 110 AWG 6*2 AWG 8
VFS15S-2002PL-W1 240 Class J 10 GV3P13 9 AWG 14 AWG 14
VFS15S-2004PL-W1 240 Class J 15 GV3P13 9 AWG 14 AWG 14
VFS15S-2007PL-W1 240 Class J 25 GV3P13 13 AWG 14 AWG 14
VFS15S-2015PL-W1 240 Class J 40 GV3P25 25 AWG 10 AWG 12
VFS15S-2022PL-W1 240 Class J 45 GV3P32 32 AWG 10 AWG 10
VFS15-4004PL-W1 480 Class J 6 GV3P13 9 AWG 14 AWG 14
VFS15-4007PL-W1 480 Class J 6 GV3P13 9 AWG 14 AWG 14
VFS15-4015PL-W1 480 Class J 15 GV3P13 9 AWG 14 AWG 14
VFS15-4022PL-W1 480 Class J 15 GV3P13 10 AWG 14 AWG 14
VFS15-4037PL-W1 480 Class J 25 GV3P13 13 AWG 12 AWG 14
VFS15-4055PL-W1 480 Class J 40 GV3P18 18 AWG 10 AWG 10
VFS15-4075PL-W1 480 Class J 40 GV3P25 25 AWG 8 AWG 10
VFS15-4110PL-W1 480 Class J 60 GV3P32 32 AWG 8 AWG 10
VFS15-4150PL-W1 480 Class J 70 GV3P40 (*1) 40 AWG 6 AWG 10
(*1) In case VFS15-4150PL with the circuit breaker, the Short Circuit Current Ratings (SCCR) is 65kA.
(*2) The manufacturer of the fuses should be "Cooper Bussmann" or "Mersen" (formerly, "Ferraz Shawmut") for the
compliance of UL standard.
(*3) The manufacturer of the listed circuit breaker is "Schneider Electric".

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
