Toshiba Tosvert VF-S15 User Manual

E6582175
17
Table 4: Parameter default setting values for traditional IE1 motor (V116 or earlier version defaults)
Type form
vb/
f172
f402 f415 f416
f417
(JP,USA)*3
f417
(ASIA,EU)*3
f456
*4
f457
*4
f458
*4
f459
% % A % min
-1
min
-1
%
－ －
Times
VFS15-2004PM-W1 6.0 6.2 2.00 65
VFS15-2007PM-W1 6.0 5.8 3.40 60
VFS15-2015PM-W1 6.0 4.3 6.20 55
VFS15-2022PM-W1 5.0 4.1 8.90 52 1710 1410 150 75 0 1.0
VFS15-2037PM-W1 5.0 3.4 14.80 48
VFS15-2055PM-W1 4.0 3.0 21.00 46
VFS15-2075PM-W1 3.0 2.5 28.20 43
VFS15-2110PM-W1 2.0 2.3 40.60 41
VFS15-2150PM-W1 2.0 2.0 54.60 38
VFS15S-2002PL-W1 6.0 8.3 1.20 70
VFS15S-2004PL-W1 6.0 6.2 2.00 65
VFS15S-2007PL-W1 6.0 5.8 3.40 60 1710 1410 150 75 0 1.0
VFS15S-2015PL-W1 6.0 4.3 6.20 55
VFS15S-2022PL-W1 5.0 4.1 8.90 52
VFS15-4004PL-W1 6.0 6.2 1.00 65
VFS15-4007PL-W1 6.0 5.8 1.70 60
VFS15-4015PL-W1 6.0 4.3 3.10 55
VFS15-4022PL-W1 5.0 4.1 4.50 52
VFS15-4037PL-W1 5.0 3.4 7.40 48 1710 1410 150 75 0 1.0
VFS15-4055PL-W1 4.0 2.6 10.50 46
VFS15-4075PL-W1 3.0 2.3 14.10 43
VFS15-4110PL-W1 2.0 2.2 20.30 41
VFS15-4150PL-W1 2.0 1.9 27.30 38
*3: Refer to section 3.1 ’How to Set the Setup Menu’ and 4.4 ‘Checking the region settings selection’.
*4: f456 to f458 are manufacturer setting parameters. However, change these parameters according to Table 4 for achieving same
motor control characteristics.
f456 and f457 are not copied from V110 or earlier version inverter by Parameter writer or other options, because f456 and
f457 do not exist on V110 or earlier version inverter. Therefore, change f456 and f457 manually.
© Toshiba Schneider Inverter Corporation 2012
S-5

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
