Toshiba Tosvert VF-S15 User Manual

E6582175
17
Table 3: Parameter default setting values for IE3 motor (V120 or later version defaults)
Type form
vb/
f172
f402 f415 f416
f417
(JP,USA)*3
f417
(ASIA,EU)*3
f456 f457 f458 f459
% % A % min
-1
min
-1
%
－ －
Times
VFS15-2004PM-W1 Same values as Table 4 (V116 or earlier version)
VFS15-2007PM-W1 4.8 4.3 3.40 55 1730 1440
VFS15-2015PM-W1 4.8 4.4 6.40 42 1740 1445
VFS15-2022PM-W1 3.1 2.9 9.40 50 1755 1460 120 50 101 1.5
VFS15-2037PM-W1 3.1 2.8 14.60 38 1755 1460
VFS15-2055PM-W1 2.5 2.3 21.40 41 1760 1465
VFS15-2075PM-W1 2.3 2.0 28.60 38 1755 1460
VFS15-2110PM-W1 1.8 1.6 42.00 38 1770 1475
VFS15-2150PM-W1 1.6 1.5 55.60 33 1760 1470
VFS15S-2002PL-W1
Same values as Table 4 (V116 or earlier version)
VFS15S-2004PL-W1
VFS15S-2007PL-W1 4.8 4.3 3.40 55 1730 1440 120 50 101 1.5
VFS15S-2015PL-W1 4.8 4.4 6.40 42 1740 1445
VFS15S-2022PL-W1 3.1 2.9 9.40 50 1755 1460
VFS15-4004PL-W1 Same values as Table 4 (V116 or earlier version)
VFS15-4007PL-W1 4.8 4.3 1.70 55 1730 1440
VFS15-4015PL-W1 4.8 4.4 3.20 42 1740 1445
VFS15-4022PL-W1 3.1 2.9 4.70 50 1755 1460
VFS15-4037PL-W1 3.1 2.8 7.30 38 1755 1460 120 50 101 1.5
VFS15-4055PL-W1 2.5 2.3 10.70 41 1760 1465
VFS15-4075PL-W1 2.3 2.0 14.30 38 1755 1460
VFS15-4110PL-W1 1.8 1.6 21.00 38 1770 1475
VFS15-4150PL-W1 1.6 1.5 27.80 33 1760 1470
*3: Refer to section 3.1 ’How to Set the Setup Menu’ and 4.4 ‘Checking the region settings selection’.
S-4

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
