Toshiba Tosvert VF-S15 User Manual

E6582175
D-12
4
Save user setting parameters (typ = 7)
Setting typ to 7 saves the current settings of all parameters.
Load user setting parameters (typ = 8)
Setting typ to 8 loads parameter settings to (calls up) those saved by setting typ to 7.
* By setting typ to 7 or 8, you can use parameters as your own default parameters.
Cumulative fan operation time record clear (typ = 9)
Setting typ to 9 resets the cumulative operation time to the initial value (zero).
Set this parameter when replacing the cooling fan, and so on
Number of starting clear (typ = 12)
Setting typ to12 resets the number of starting to the initial value (zero).
Default setting 2 (typ = 13)
Set typ to 13 to return all parameters to their default settings.
When 13 is set, init is displayed for a short time after the settings are configured, and then
disappears. Then setup menu set is displayed. After reviewing the setup menu items, make a setup
menu selection. In this case, all parameters are returned to their defaults, and the trip history data is cleared.
(Refer to section 3.1)

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
