Toshiba Tosvert VF-S15 User Manual

E6582175
D-16
4
[How to select parameters]
Select the desired parameters as easy setting mode parameters 1 to 32 (f751 to f782). Note that parameters
should be specified by communication number. For communication numbers, refer to Table of parameters.
In easy setting mode, only parameters registered to parameters 1 to 32 are displayed in order of registration.
The values of the default settings are shown in the table below.
[Parameter setting]
Title Function Adjustment range Default setting
f751
Easy setting mode parameter 1 0-2999
3（cmod）
f752
Easy setting mode parameter 2 0-2999
4（fmod）
f753
Easy setting mode parameter 3 0-2999
9（acc）
f754
Easy setting mode parameter 4 0-2999
10（dec）
f755
Easy setting mode parameter 5 0-2999
12（ul）
f756
Easy setting mode parameter 6 0-2999
13（ll）
f757
Easy setting mode parameter 7 0-2999
600（thr）
f758
Easy setting mode parameter 8 0-2999
6（fm）
f759 Easy setting mode parameter 9
0-2999
(Set by communication number)
999
(No function)
f760
Easy setting mode parameter 10
f761 Easy setting mode parameter 11
f762
Easy setting mode parameter 12
f763
Easy setting mode parameter 13
f764 Easy setting mode parameter 14
f765
Easy setting mode parameter 15
f766 Easy setting mode parameter 16
f767
Easy setting mode parameter 17
f768
Easy setting mode parameter 18
f769
Easy setting mode parameter 19
f770
Easy setting mode parameter 20
f771 Easy setting mode parameter 21
f772
Easy setting mode parameter 22
f773
Easy setting mode parameter 23
f774
Easy setting mode parameter 24
f775
Easy setting mode parameter 25
f776
Easy setting mode parameter 26
f777
Easy setting mode parameter 27
f778
Easy setting mode parameter 28
f779
Easy setting mode parameter 29
f780
Easy setting mode parameter 30
f781
Easy setting mode parameter 31 0-2999
701（f701）
f782
Easy setting mode parameter 32 0-2999
50（psel）
Note: If any number other than communication numbers is specified, it is regarded as 999 (no function assigned).

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
