4. Operation of Pull Tester with H52 Dynamic Search (HB10/HB16)
5. Operation of Pull Tester with H52 Dynamic Search
- The pull-hook is moved to Pull Position by press Bond Button.
- with H52 Dynamic Search adjust position with up and down.
- To Start Pull, press Bond Button again
- Bond head move up to rest position
- Now you can read the breaking force at the force gauge. The unit is grams.
- Finally reset clock by returning the red pointer back to zero.
