CDHH-SVX003C-EN

Weights (kg)

Important: The weight information provided here should be

used for general information only. Trane does

not recommend using this weight information

for considerations relative to chiller handling,

rigging, or placement. The large number of

variances between chiller selections drives

variances in chiller weights that are not

recognized in these tables. For specific

weights for your chiller, refer to your submittal

package.

Table 5. Representative weights, 60 Hz chillers (kg)

Model

Comp Size

CPKW

Evap Size

Cond Size

Weights without Starters

NTON EVSZ CDSZ

Operating Shipping

CDHH

2000–2600 1340 400M 440M 56437 45781

2800–3300 1340 440M 440M 60907 49124

2800–3300 1340 440X 440X 64235 51446

Notes:

1. TECU tubes, 0.71 mm tube wall thickness.

2. 2068.4 kPaG marine waterboxes.

3. Heaviest possible bundle and motor combination.

4. Operating weights assume the largest possible refrigerant charge.

5. Industrial Control Panel (INDP) option, add 23 kg.

6. Control Power Transformer (CPTR) option, add 127 kg.

7. Supplemental Motor Protection (SMP) option, add 227 kg.

8. To calculate the maximum chiller weight with starter/drive, add the starter/AFD weight from the following table (maximum weights, unit-mounted starters/AFDs [kg]) to

the chiller maximum weight from this table. Note that Duplex™ chiller models CDHH will have two starters, one for each compressor.

Table 6. Representative weights, 50 Hz chillers (kg)
