CDHH-SVX003C-EN
9
Compressor Nameplate
The compressor assembly has a separate model number
which is required to identify internal and external
compressor parts. The model number begins with “CCHH”
and the nameplate is located on the foot of the volute.
Figure 2. Compressor nameplate
TRANE MADE IN USA X39002458010B
MODEL NO.
SALES ORDERSERIAL NO.
Note: The serial number space on the compressor
nameplate will be intentionally left blank.
Pressure Vessel Nameplates
Figure 3. ASME nameplate (all dimensions are metric)
Unit Nameplate
