Module Installation
Air-Fi
®
For installation instructions, see BAS-SVN038*-EN, Air-Fi
®
Wireless Communications Interface (WCI) Installation
Instructions.
Recommended routing from Air-Fi
®
module to Symbio™
800 using factory provided mounting provision is shown in
figure below. Device can be remote mounted in order to
obtain a stronger signal.
Figure 38. Air-Fi
®
wire harness routing path
