Triumph Speed Triple RS User Manual

Maintenance
104
Coolant Level Adjustment
Warning
Do not remove the radiator pressure
cap when the engine is hot.
When the engine is hot, the coolant in-
side the radiator will be hot and also
under pressure.
Contact with this hot, pressurised cool-
ant will cause scalds and skin damage.
Caution
If hard water is used in the cooling
system, it will cause scale accumulation
in the engine and radiator and consid-
erably reduce the efficiency of the
cooling system.
Reduced cooling system efficiency may
cause the engine to overheat and suf-
fer severe damage.
To adjust the coolant level:
• Allow the engine to cool.
• To access the expansion tank, raise
and support the fuel tank (see
page 105).
• Remove the cap from the expan-
sion tank and add coolant mixture
through the filler opening until the
level reaches the MAX mark on the
expansion tank cover.
12
1. Expansion tank
2. Tank cap
• Refit the cap.
• Lower and secure the fuel tank (see
page 106).
Note:
• If the coolant level is being checked
because the coolant has overheat-
ed, also check the level in the
radiator and top up if necessary.
• In an emergency, distilled water
can be added to the cooling system.
However, the coolant must then be
drained and replenished with HD4X
Hybrid OAT coolant as soon as pos-
sible.

Triumph Speed Triple RS Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, inline 3-cylinder
Engine Capacity	1160 cc
Max Torque	125 Nm @ 9, 000 rpm
Transmission	6-speed
Seat Height	830 mm
Weight	198 kg (wet)
Max Power	180 PS (132.4 kW) @ 10, 750 rpm
Rear Suspension	Ohlins TTX36 twin tube monoshock, fully adjustable
Front Brakes	Brembo Stylema, 320 mm twin disc
Rear Brakes	Brembo single piston caliper, single 220 mm disc
Fuel Tank Capacity	15.5 litres
Front Suspension	Öhlins 43mm NIX30 upside down forks, fully adjustable
