Triumph Speed Triple RS User Manual

General Information
69
Filling the Fuel Tank
Warning
Overfilling the tank can lead to fuel
spillage.
If fuel is spilled, thoroughly clean up
the spillage immediately and dispose of
the materials used safely.
Take care not to spill any fuel on the
engine, exhaust pipes, tyres or any
other part of the motorcycle.
Because fuel is highly flammable, any
fuel leak or spillage, or any failure to
observe the safety advice given above
may lead to a fire hazard, which could
cause damage to property and injury
or death to persons.
Fuel spilled near to, or onto the tyres
will reduce the tyres’ ability to grip the
road. This will result in a dangerous
riding condition potentially causing loss
of motorcycle control and an accident.
Caution
Avoid filling the tank in rainy or dusty
conditions where airborne material can
contaminate the fuel.
Contaminated fuel may cause damage
to fuel system components.
Fill the fuel tank slowly to help prevent
spillage. Do not fill the tank to a level
above the bottom of the filler neck. This
will make sure there is enough air space
to allow for fuel expansion if the fuel in-
side the tank expands through
absorption of heat from the engine or
from direct sunlight.
2
1
1. Fuel filler neck
2. Maximum fuel level
After refuelling always check that the
fuel filler cap is correctly closed.

Triumph Speed Triple RS Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, inline 3-cylinder
Engine Capacity	1160 cc
Max Torque	125 Nm @ 9, 000 rpm
Transmission	6-speed
Seat Height	830 mm
Weight	198 kg (wet)
Max Power	180 PS (132.4 kW) @ 10, 750 rpm
Rear Suspension	Ohlins TTX36 twin tube monoshock, fully adjustable
Front Brakes	Brembo Stylema, 320 mm twin disc
Rear Brakes	Brembo single piston caliper, single 220 mm disc
Fuel Tank Capacity	15.5 litres
Front Suspension	Öhlins 43mm NIX30 upside down forks, fully adjustable
