Triumph Speed Triple RS User Manual

Parts Identification
12
PARTS IDENTIFICATION
2
3
4
6
7
8
11
12 13 14 159 10
1
5
1. Headlight
2. Radiator/Coolant pressure cap
3. Fuel filler cap
4. Fuel tank
5. Coolant expansion tank
6. Seat lock
7. Silencer
8. Rear light
9. Front brake disc
10. Front brake caliper
11. Front indicator
12. Oil cooler
13. Side stand
14. Gear change pedal
15. Drive chain

Triumph Speed Triple RS Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, inline 3-cylinder
Engine Capacity	1160 cc
Max Torque	125 Nm @ 9, 000 rpm
Transmission	6-speed
Seat Height	830 mm
Weight	198 kg (wet)
Max Power	180 PS (132.4 kW) @ 10, 750 rpm
Rear Suspension	Ohlins TTX36 twin tube monoshock, fully adjustable
Front Brakes	Brembo Stylema, 320 mm twin disc
Rear Brakes	Brembo single piston caliper, single 220 mm disc
Fuel Tank Capacity	15.5 litres
Front Suspension	Öhlins 43mm NIX30 upside down forks, fully adjustable
