General Information
53
This is a four position, key operated
switch. The key can be removed from
the switch only when it is in the OFF,
LOCK or P (PARK) position.
P
U
S
H
P
O
F
F
O
N
3
2
5
1
4
1. PARK position
2. LOCK position
3. OFF position
4. ON position
5. Ignition switch/Steering lock
To lock the steering:
Turn the steering fully to the left.
Turn the key to the OFF position.
Push and fully release the key.
Rotate it to the LOCK position.
To park:
Turn the key from the LOCK posi-
tion to the P position.
The steering will remain locked.
Engine Immobiliser
The ignition barrel housing acts as the
antenna for the engine immobiliser.
When the ignition switch is turned to
the OFF position and the ignition key re-
moved, the engine immobiliser is on. The
engine immobiliser is turned off when
the ignition key is in the ignition switch
and it is turned to the ON position.
Right Handlebar Switches
Speed Triple RS
1
3
4
5
7
6
2
8
1. HOME button
2. Engine start/stop switch
3. QUICK START position
4. RUN position
5. STOP position
6. Power ON/OFF position
7. Hazard warning lights switch
8. Steering lock button
The following sections describe the han-
dlebar buttons and switches functions.
HOME Button
The HOME button is used to access the
main menu on the instrument display.
Press and release the HOME button to
select between the main menu and in-
strument display.
