Triumph Speed Triple RS User Manual

General Information
73
Universal Serial Bus (USB)
Socket
Warning
The USB socket is not waterproof un-
less the waterproof cap is installed. Do
not connect electronic devices whilst it
is raining.
Water in the USB socket could lead to
an electrical problem, resulting in mo-
torcycle damage, loss of motorcycle
control and an accident.
Caution
Do not leave the ignition switch in the
ON position unless the engine is run-
ning as this will discharge the battery.
Caution
Make sure that all electronic devices
and cables are safely secured under
the seat when riding.
Make sure there is sufficient space
surrounding any electronic devices for
the seat to close without causing any
damage to the electronic device or the
motorcycle.
The Universal Serial Bus (USB) socket al-
lows a 5 Volt USB connection for
charging electronic devices such as mo-
bile phones, cameras and GPS devices.
Loads up to a maximum of 2 Amps can
be connected to the USB socket.
To access the USB socket:
• Remove the passenger seat, see
page 70.
• The USB socket is located in the
centre.
ckfp
1
1. USB Port Socket
• Remove the cap.
• Insert the relevant USB adaptor ca-
ble into the USB port socket.
Note:
• Adaptor cables are not supplied
with the motorcycle.

Triumph Speed Triple RS Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, inline 3-cylinder
Engine Capacity	1160 cc
Max Torque	125 Nm @ 9, 000 rpm
Transmission	6-speed
Seat Height	830 mm
Weight	198 kg (wet)
Max Power	180 PS (132.4 kW) @ 10, 750 rpm
Rear Suspension	Ohlins TTX36 twin tube monoshock, fully adjustable
Front Brakes	Brembo Stylema, 320 mm twin disc
Rear Brakes	Brembo single piston caliper, single 220 mm disc
Fuel Tank Capacity	15.5 litres
Front Suspension	Öhlins 43mm NIX30 upside down forks, fully adjustable
