Triumph Speed Triple RS User Manual

How to Ride the Motorcycle
77
Stopping the Engine
Speed Triple RS
25
8
6
4
2
0
12
14
25.2
mp/h
MM
RPM
x1000
10
N
3
2
1
1. Neutral indicator light
2. Engine stop switch - STOP position
3. Master ignition switch - OFF position (if
fitted)
To stop the engine:
• Close the throttle completely.
• Select neutral.
• Place the engine stop switch in the
STOP position.
• Turn the master ignition switch to
the OFF position (if fitted).
• Select first gear.
• Support the motorcycle on a firm,
level surface with the side stand.
• Lock the steering.
Caution
Do not leave the ignition switched on
with the engine stopped. This will
cause electrical damage.
Stopping the Engine
Speed Triple S
25
8
6
4
2
0
12
14
25.2
mp/h
MM
RPM
x1000
10
N
P
U
S
H
P
O
F
F
O
N
41
3
2
1. Neutral indicator light
2. OFF position
3. Ignition switch
4. Engine stop switch - STOP position
To stop the engine:
• Close the throttle completely.
• Select neutral.
• Turn the ignition switch off.
• Place the engine stop/start switch
in the STOP position.
• Select first gear.
• Support the motorcycle on a firm,
level surface with the side stand.
• Lock the steering.
Caution
The engine should normally be stopped
by turning the ignition switch to the
OFF position.
The engine stop switch is for emergen-
cy use only.
Do not leave the ignition switched on
with the engine stopped. This will
cause electrical damage.

Triumph Speed Triple RS Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, inline 3-cylinder
Engine Capacity	1160 cc
Max Torque	125 Nm @ 9, 000 rpm
Transmission	6-speed
Seat Height	830 mm
Weight	198 kg (wet)
Max Power	180 PS (132.4 kW) @ 10, 750 rpm
Rear Suspension	Ohlins TTX36 twin tube monoshock, fully adjustable
Front Brakes	Brembo Stylema, 320 mm twin disc
Rear Brakes	Brembo single piston caliper, single 220 mm disc
Fuel Tank Capacity	15.5 litres
Front Suspension	Öhlins 43mm NIX30 upside down forks, fully adjustable
