Triumph Speed Triple RS User Manual

General Information
26
Speedometer and Odometer
The speedometer indicates the road
speed of the motorcycle.
The odometer shows the total distance
that the motorcycle has travelled.
Tachometer
Caution
Never allow engine speed to enter the
red zone as severe engine damage may
result.
The tachometer shows the engine
speed in revolutions per minute - rpm
(r/min). At the end of the tachometer
range there is the red zone.
Engine speeds in the red zone are above
maximum recommended engine speed
and are also above the range for best
performance.
Gear Position Display
The gear position display indicates
which gear (one to six) has been en-
gaged. When the transmission is in
neutral (no gear selected), the display
will show N.
o7:29
12.5
1
9999 02:25
8
6
4
2
0
12
14
25.2
F
E
TRIP
mi mp/hHH:MM
PM
RPM
x1000
10
1
N
1. Gear position display (neutral position
shown)
o7:29
12.5
1
9999 02:25
8
6
3
4
2
0
12
14
25.2
F
E
TRIP
mi mp/hHH:MM
PM
RPM
x1000
10
1
1. Gear position display (third gear
shown)

Triumph Speed Triple RS Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, inline 3-cylinder
Engine Capacity	1160 cc
Max Torque	125 Nm @ 9, 000 rpm
Transmission	6-speed
Seat Height	830 mm
Weight	198 kg (wet)
Max Power	180 PS (132.4 kW) @ 10, 750 rpm
Rear Suspension	Ohlins TTX36 twin tube monoshock, fully adjustable
Front Brakes	Brembo Stylema, 320 mm twin disc
Rear Brakes	Brembo single piston caliper, single 220 mm disc
Fuel Tank Capacity	15.5 litres
Front Suspension	Öhlins 43mm NIX30 upside down forks, fully adjustable
