Triumph Speed Triple RS User Manual

General Information
36
Note:
• TRIP 2 meter can be shown or hid-
den from the information tray. For
more information, see page 43.
To reset a trip meter:
• Select the trip meter to be reset.
• Press and hold the joystick centre
for more than one second.
• The trip meter will then be reset.
The trip meter can also be reset from
the Main menu, see page 41.
Main Menu
To access the Main menu:
• The motorcycle must be stationary
with the ignition switched on.
• Press the HOME button on the
right handlebar switch housing.
• Scroll the Main menu by pushing
the joystick down/up until the re-
quired option is selected and then
press the joystick centre to con-
firm.
Main Menu Screen
The Main menu allows access to the fol-
lowing options:
Riding Modes
This menu allows configuration of the
riding modes. For more information, see
page 38.
Bike Set Up
This menu allows configuration of the
different features of the motorcycle. For
more information, see page 39.
Trip Set Up
This menu allows configuration of Trip 1
and Trip 2. For more information, see
page 41.
Display Set Up
This menu allows configuration of the
display options. For more information,
see page 43.
Reset to Defaults
This menu allows all instrument settings
to be returned to the default setting.
For more information, see page 48.
Riding Modes Menu
The Riding Modes menu allows configu-
ration of the riding modes.

Triumph Speed Triple RS Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, inline 3-cylinder
Engine Capacity	1160 cc
Max Torque	125 Nm @ 9, 000 rpm
Transmission	6-speed
Seat Height	830 mm
Weight	198 kg (wet)
Max Power	180 PS (132.4 kW) @ 10, 750 rpm
Rear Suspension	Ohlins TTX36 twin tube monoshock, fully adjustable
Front Brakes	Brembo Stylema, 320 mm twin disc
Rear Brakes	Brembo single piston caliper, single 220 mm disc
Fuel Tank Capacity	15.5 litres
Front Suspension	Öhlins 43mm NIX30 upside down forks, fully adjustable
