Triumph Speed Triple RS User Manual

General Information
43
The following table shows two examples
of the automatic trip reset functionality.
Ignition
Turned Off
Selected
Time Delay
Trip Meter
Resets to
Zero
10:30 hrs 4 HRS 14:30 hrs
18:00 hrs 16 HRS 10:00 hrs
(next day)
Trip 2 Enable/Disable
Trip 2 meter can be enabled or disabled.
If Trip 2 is disabled it will no longer be
shown in the information tray.
To enable or disable the Trip 2 meter:
• Push the MODE button to display
the MAIN MENU.
• Push the joystick down to select
TRIP SET UP.
• Push the joystick centre to display
the TRIP SET UP menu.
• Push the joystick down/up to scroll
to the TRIP 2 DISPLAY and press
the joystick centre.
• Push the joystick down/up to scroll
between ENABLED and DISABLED
and press the joystick centre.
Display Set Up Menu
The Display Set Up menu allows config-
uration of the different display screen
options.
To access the Display Set Up menu:
• Press the HOME button to display
the Main menu.
• Push the joystick down and then
press the joystick centre to select
DISPLAY SET UP.
The following options are available:
• Styles and Themes
• Brightness
• Visible Tray
• Language
• Set Units
• Set Clock
• Set Date.

Triumph Speed Triple RS Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, inline 3-cylinder
Engine Capacity	1160 cc
Max Torque	125 Nm @ 9, 000 rpm
Transmission	6-speed
Seat Height	830 mm
Weight	198 kg (wet)
Max Power	180 PS (132.4 kW) @ 10, 750 rpm
Rear Suspension	Ohlins TTX36 twin tube monoshock, fully adjustable
Front Brakes	Brembo Stylema, 320 mm twin disc
Rear Brakes	Brembo single piston caliper, single 220 mm disc
Fuel Tank Capacity	15.5 litres
Front Suspension	Öhlins 43mm NIX30 upside down forks, fully adjustable
